INTRODUCTION
The HDMI™ to HDMI™ + Audio converter allows you to extract an audio signal from any HDMI™ source. Ideal for splitting the audio out of an HDMI™ device to a digital surround sound system, or to an analog speaker system. Another use is to extract audio when connecting to a display monitor without built-in speakers.
FEATURES
- No need to install drivers, portable, flexible, plug and play.
- Support 12-bit Deep Full HD, Full 3D, and 4K@60Hz YUV 4:4:4.
- Support HDCP2.2.
- Support High Dynamic Range.
- Support Consumer Electronics Control function.
- Support Audio Return Channel function.
- Support 2.0CH/5.1CH/PASS audio switching.
- Support HDMI output audio format: DTS-HD Master Audio™ / Dolby TrueHD.
SPECIFICATIONS
Input Video Signal
- HDMI Signal
Input/ Output Connector
- HDMI
Dimension(mm)
- 70(D)x60(W)x21(H)
Net Weight(g)
- 123
Vertical Frequency Range
- 50/60Hz
Video Amplifier Bandwidth
- 6.0Gbps/600MHz per channel
Interlaced Resolutions(50&60Hz)
- 480i, 576i, 1080i
Progressive Resolutions(50&60Hz)
- 480p, 576p, 720p, 1080p, 4K@30Hz, 4K@60Hz
Limited Warranty
- 1 Year Parts and Labor
Operating Temperature
- 0℃ to 70℃
Operating Humidity
- 10% to 85% RH (no condensation)
Storage Temperature
- -10℃ to +80℃
Storage Humidity
- 5% to 90% RH (no condensation)
Power Supply
- 5V DC
Power Consumption
- 5W
Converter Unit Cert
- FCC, CE, RoHS
User Manual
- English Version
Note: Specifications are subject to change without notice.
