INTRODUCTION
This HDMI™ 2 ports Splitter lets you share two HDMI™ displays or projectors with an HDMI™-enabled audio / video source device, such as a computer, Blu-ray player or cable TV set-top box. With support for Ultra HD (4K) the HDMI™ splitter ensures astonishing picture quality, four times the resolution of high-definition 1080p. The 4K splitter is also backward compatible with previous HDMI™ revisions, supporting 1080p / 720p HDMI video resolution devices. With one fixed HDMI cable (pigtail), this splitter is cost-effective and time-saving.
FEATURES
- Support full 3D video format.
- Support high definition resolution 4K@30Hz.
- Support 340MHz/3.4Gbps per channel bandwidth (10.2Gbps all channels).
- Support 12bit per channel (36bit all channels) deep color.
- Support HDCP1.4.
- Support Consumer Electronics Control function.
- Support uncompressed audio such as LPCM.
- Support compressed audio such as DTS, Dolby Digital (including DTS-HD Master Audio™ and Dolby TrueHD).
SPECIFICATIONS
Input Ports
- HDMI x 1
Output Ports
- HDMI x 2
Vertical Frequency Range
- 50/60Hz
Video Amplifier Bandwidth
- 3.4Gbps/3400MHz per channel(10.2Gbps all channels)
Interlaced(50&60Hz)
- 480i,576i,1080i
Progressive(50&60Hz)
- 480p,576p,720p,1080p,4K@24/30Hz
Limited Warranty
- 1 Year Parts and Labor
Operating Temperature
- 0℃ to 70℃
Storage Humidity
- 5% to 90% RH non-condensation
Power Supply
- N/A
Power Consumption (Max)
- 5W
Switcher Unit Cert
- FCC, CE, RoHS
Dimension(LxWxH)
- 71.5x32x14.5mm
Net Weight
- 28g
Material
- ABS
User Manual
- English Version
Note: Specifications are subject to change without notice.
