INTRODUCTION
The HDMI™ 4K splitter 1×8 lets you share eight HDMI™ displays or projectors with an HDMI-enabled audio / video source device. With support for Ultra HD (4K@30Hz) the HDMI™ splitter ensures astonishing picture quality, four times the resolution of HD 1080p@60 Hz. The 4K splitter is also backward compatible with previous HDMI™ revisions, supporting 1080p / 720p HDMI™ video resolution devices. Even if you don’t require 4K video today, the HDMI™ 4K Splitter 1×8 ensures you’ll be ready to take advantage of tomorrow’s display technology.
FEATURES
- Support full 3D video format.
- Support high resolution up to 4K@30Hz.
- Support HDCP 1.4.
- Support 340MHz/3.4Gbps per channel (10.2Gbps all channels) bandwidth.
- Support 12bit per channel (36bit all channels) deep color.
- Support uncompressed audio such as LPCM.
- Support compressed audio such as DTS, Dolby Digital (including DTS-HD Master Audio™ and Dolby TrueHD).
SPECIFICATIONS
Input Ports
- HDMI x 1
Output Ports
- HDMI x 8
Vertical Frequency Range
- 50/60Hz
Video Amplifier Bandwidth
- 3.4Gbps/340MHz per channel(10.2Gbps all channels)
Interlaced(50&60Hz)
- 480i,576i,1080i
Progressive(50&60Hz)
- 480p,576p,720p,1080p,4K@24/30Hz
Limited Warranty
- 1 Year Parts and Labor
Operating Temperature
- 0℃ to 70℃
Storage Humidity
- 5% to 90% RH non-condensation
Power Supply
- DC 5V@2A Power Adapter
Power Consumption (Max)
- 10W
Splitter Unit Cert
- FCC, CE, RoHS
Power Supply Cert
- FCC, CE, RoHS
Power Adapter Standard
- US, EU, UK, AU Standard etc.
Dimension(LxWxH)
- 222*83*14.5mm
Net Weight
- 387g
Material
- Metal
User Manual
- English Version
Note: Specifications are subject to change without notice.
