USB 3.0 to HDMI™ Dual 4K@60Hz Display Adapter

Package Content

INTRODUCTION

The USB 3.0 to Dual HDMI™ 4K@60Hz Adapter, which connects USB-A or USB-C to two HDMI™ displays. This adapter is designed to support Mirror/Extend/Rotation/Clamshell modes and can display up to 4K@60Hz on both output. We have tested this product to meet all specifications and features. To ensure long-term enjoyment of this product, please read the following information before installation.

FEATURES
  • Supports dual displays output at 4K@60Hz max.
  • Supports video decoding in multiple formats, including H.264, H.263, MP4, MP2, DivX, AVS, JPEG, and more.
  • Compatible with USB-C, USB 3.2 Gen 1 (5Gbps), Thunderbolt 3/4, and USB 4 standard ports.
  • Works with macOS enabling extended dual displays on USB-C and Thunderbolt 3/4 laptops including Apple M1 / M2 MacBooks which are not natively capable of driving more than one external display; Requires Driver Download for macOS.
  • Universal Adapter works w/ Windows, macOS, Ubuntu, and ChromeOS; Automatic driver install in Windows & ChromeOS.
  • Connect additional displays when extra video ports are not available on the laptop or dock; Use with two external monitors and a workstation laptop screen; Ideal for business productivity apps, not ideal for gaming.
  • Allows you to extend your PC screen to multiple displays, supporting up to 6 displays on Windows and up to 4 displays on Mac OS.
SPECIFICATIONS
Input Ports

  • USB-C Male or USB 3.0 Male x 1

Output Ports

  • HDMI x 2

Data Transmission Rate (Max)

  • 5Gbps

Data Transmission Standard

  • USB 3.0 ( USB 3.1 GEN 1)

Compatible OS

  • Windows 7/8.1/10/11 and above
    Mac OS 10.10.x and above
    Android 7.1 and above( Android devices only support mirroring mode with resolutions up to 1080P)

Operating Temperature

  • 0℃ to 60℃

Storage Humidity

  • 5% to 90% RH non-condensation

Power Supply

  • USB3.0 USB-C from PC or notebook

Power Consumption (Max)

  • 5W

Unit Cert

  • FCC, CE, RoHS

Dimension (LxWxH)

  • 3.94x 2.05×0.53in (100x52x13.5mm)

Net Weight

  • 78g

Material

  • ABS

User Manual

  • English Version

Note: Specifications are subject to change without notice.
